Two Wire Fluting Paper Machine Grey With Cooking System And Size Press

Name: Two Wire Fluting Paper Machine Grey With Cooking System And Size Press
Brand: PingAn
Price: 1 USD

Quality Two Wire Fluting Paper Machine Grey With Cooking System And Size Press for sale

Brand Name : PingAn

Model Number : 3800mm

Certification : ISO9001:2008

Place of Origin : Henan, China

MOQ : 1set

Price : Negotiation

Payment Terms : T/T, L/C

Supply Ability : 5sets/year

Delivery Time : 8 month

Packaging Details : wooden case

Item : Two wire fluting paper machine

Size press : yes

Color : Grey or customized

Cooking system : yes

Warranty : 1 year

Output : Fluting paper and high strength fluting paper

Contact Now

Two wire fluting paper machine with cooking system and size press

Description

This paper making machine is used to produce fluting paper and high strength fluting paper based on the gsm of 90-180g/m² .

This two wire fluting paper making machine is composed of :

wire forming section, press section, dryer section, paper pop reel, base section and auxiliary system etc.

Structure of this two wire fluting paper making machine

Forming section	Air cushion type headbox (single wire length 20m)
Press section	One vacuum pickup+one vacuum press+on big jumbo roll press
Dryer section	34sets dryer cylinders
Reeling section	Horizontal reeling machine

Main technical parameters

Output: High trenghth fluting paper and fluting paper
Gammage: 90-180g/m²
Net paper width: 3800mm
Reeling width: 3860mm
Headbox lip width: 4200mm
Designed speed: 380m/min
Dynamic balance speed: 450m/min
Working speed: 300-350m/min

Main performance requirements and guarantee

This paper making machine can reach the scheduled production capacity150 tons per day at 112gsm (22.5 hours, with size press) . Also take the paper making machine’s inner and exterior performance requirements into consideration at first. This is full set of new paper machine which is well-designed and precision machined.
